11
4
BASIC OPERATION
Receive mode selection
Receive modes are determined by the physical properties of
the radio signals. The transceiver has 3 receive modes: FM,
AM and WFM modes.The mode selection is stored indepen-
dently in each band and memory channels.
Typically, AM mode is used for the air band (118135.995
MHz) and WFM is used for FM broadcast stations (76107.9
MHz).
When pushing [PTT], a beep tone sounds indicating the
mode is not FM mode. The transceiver cannot transmit in
AM or WFM mode.
DSetting the receive mode
q Push [V/M] for 2 sec. to enter set
mode.
w Rotate [DIAL] until MOD ap-
pears.
•“MOD disappears after 1 sec. and
the previously selected receive mode
and md appear.
e While pushing [FUNC], rotate
[DIAL] to select the desired re-
ceive mode.
r Push [V/M] to exit set mode.
Display backlighting
The transceiver has display backlighting with a 5 sec. timer
for nighttime operation. The display backlighting can be
turned ON continuously or turned OFF, if desired.
Push any switch except [PTT] and [FUNC]; or, rotate [DIAL]
to turn the backlighting ON.
When auto backlighting is set, the backlighting will automatically
turn OFF when switches and [DIAL] have not been operated for 5
sec.
DSetting the backlighting setting
q Push [V/M] for 2 sec. to enter set
mode.
w Rotate [DIAL] until LIGHT ap-
pears.
•“LIGHTdisappears after 1 sec. and
the previously selected backlighting
timer and LIappear.
e While pushing [FUNC], rotate
[DIAL] to select the desired back-
lighting setting.
r Push [V/M] to exit set mode.
Automatic backlighting
Backlighting set mode
Continuously OFF
AM mode
Receive mode set mode
FM mode
