Icom IC-Q7A [34/43] I auto power off function
![Icom IC-Q7A [34/43] I auto power off function](/views2/1074437/page34/bg22.png)
30
10
OTHER FUNCTIONS
■ Auto power-off function
The transceiver can be set to automatically turn OFF after a
specified period in which no switch is pushed.
120 min., 90 min., 60 min., 30 min. and OFF can be speci-
fied. The specified period is retained even when the trans-
ceiver is turned OFF by the auto power-off function.To cancel
the function, select “OFF” in step e below.
q Push [V/M] for 2 sec. to enter expanded set mode.
w Rotate [DIAL] until “AP OFF” appears.
•Turn the expanded set mode ON for selection. (p.28)
•“AP OFF” disappears after 1 sec.and “AO” appears.
e While pushing [FUNC], rotate [DIAL] to select the desired
time or to turn the function OFF.
r Push [V/M] to exit set mode.
■ Monitor switch function
The monitor switch can be set as a sticky switch.When set to
the sticky condition, each push of [SQL] toggles the monitor
function on and off.
q Push [V/M] for 2 sec. to enter expanded set mode.
w Rotate [DIAL] until “MONI” appears.
•Turn the expanded set mode ON for selection. (p.28)
•“MONI” disappears after 1 sec.and “mO” appears.
e While pushing [FUNC], rotate [DIAL] to set the monitor
switch to sticky (HOLD) or normal (PUSH).
r Push [V/M] to exit set mode.
60 min. auto power-offAuto power off set
mode
Auto power-off is
turned OFF.
Sticky switchMonitor switch
function set mode
Normal switch
