ii
Even when the transceiver power is OFF, a slight current still
flows in the circuits. Remove batteries from the transceiver
when not using it for a long time.Otherwise, the installed bat-
teries will become exhausted.
For U.S.A. only
CAUTION:Changes or modifications to this device, not ex-
pressly approved by Icom Inc., could void your authority to
operate this device under FCC regulations.
SUPPLIED ACCESSORIES
Accessories included with the transceiver: Qty.
q Antenna (FA-S270C) ...................................................... 1
w Handstrap ....................................................................... 1
e Belt clip ........................................................................... 1
