SiBE27-702 Expansion Valve Regulating Functions
Functional Description 89
5.3 Discharge Pipe Temperature Protection Control
Outline The expansion valve opening will be controlled in order to avoid abnormal high compressor
discharge temperatures (see also compressor operating frequency control).
Details
RZQ71B9, RZQS71·100B7V3B (1 phase), RZQ100~140B8W1B (3 phase)
RZQ100~140C7, RZQS125·140C7V1B (1 phase)
Normal operation
Electronic expansion valve opening degree lower limit
+5 pulses/Cooling for 2 minutes & heating for 1 minute
Td > 95°C
Td < 80°C
Td>95˚C
Td<90˚C
Td<80˚C
Td>100˚C
Electronic expansion valve opening
degree lower limit
+5 pulses/Cooling for 2 minutes &
heating for 1 minute
Electronic expansion valve opening
degree lower limit
-5 pulses/Cooling for 2 minutes &
heating for 1 minute
Electronic expansion valve opening
degree lower limit
+10 pulses/Cooling for 2 minutes &
heating for 1 minute
Normal control
Td: Compressor discharge pipe temperature (˚C)
