Daikin RZQ100B8W1B [72/344] Preheating operation control
![Daikin RZQ100B8W1B [72/344] Preheating operation control](/views2/1769683/page72/bg48.png)
SiBE27-702 General Functionality
Functional Description 59
1.16 Preheating Operation Control
RZQ71B9, RZQS71·100B7V3B (1 phase)
Outline After the compressor has been turned off, the preheating operation will be activated in order to
avoid refrigerant from dissolving in the compressor oil.
Trigger
conditions
Starting conditions &
•or
• T2 (Discharge pipe temperature) < 40°C
• Ta (Outside temperature) < 40°C
• Power supply ON to First operation
• 60 minutes or more elapsed after compressor stop
Ending conditions or
• T2 (Discharge pipe temperature) > 43°C
• Ta (Outside temperature) > 43°C
• Thermostat ON confirmation
