Troubleshooting by Remote Controller Display / LED Display SiBE27-702
186 Troubleshooting
Troubleshooting
*1: Connector code: X31A
*2: Method of voltage measurement
*3: Pressure/ voltage characteristic of the sensor
Replace the low pressure
sensor.
Correct the failure.
Replace the outdoor
control PC board (A1P).
NO
NO
YES
YES
Connect correctry.
NO
YES
Check 7
Is low pressure
abnormally
low?
Open the stop valve.
NO
YES
Check the installation
conditions
(P244)
Is the stop valve
open?
Is the
connector (*1)
for the low-pressure
sensor correctly connected
to the outdoor unit
PC board?
Measure the voltage (DC)
between the pins (2) and (3)
of the connector (refer to *2).
Is the
converted pressure
based on the measured
voltage normal?
(refer to *3).
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Output voltage V
PL: detected pressure (Mpa)
V: output voltage (V)
1.5
1.0
0.5
0
-
0.5
0
-
0.5 0.5 1 1.5 2 2.5 3 3.5 4
Vcc
PL=0.57V
-
0.28
PL
Detected pressure PL (MPa)
