Outdoor Unit Fan Speed Control SiBE27-702
90 Functional Description
6. Outdoor Unit Fan Speed Control
6.1 Outdoor Unit Fan Speed Control
Fan speed
control
The outdoor fan speed will be controlled in function of the actual outdoor ambient temperature,
the condensation pressure, pressure difference between low and high pressure and
compression ratio.
For details please refer to "Pressure Difference Control".
Fan step table
RZQ71B9,
RZQS71·100B7V3B
Fan step table
RZQ100~140C7,
RZQS125·140C7V1B
Fan step table
RZQ100~140B8W1B
Note: Refer to "Pressure Difference Control" on P83
Refer to "Defrost Operation" on P53
Step Cooling Heating
0 0 rpm 0 rpm
1 200 rpm 200 rpm
2 250 rpm 250 rpm
3 300 rpm 300 rpm
4 360 rpm 360 rpm
5 430 rpm 430 rpm
6 515 rpm 515 rpm
7 620 rpm 715 rpm
8 818 rpm 738 rpm
Cooling Heating
Step M1F M2F M1F M2F
0 0 rpm 0 rpm 0 rpm 0 rpm
1 250 rpm 0 rpm 250 rpm 0 rpm
2 400 rpm 0 rpm 285 rpm 250 rpm
3 285 rpm 250 rpm 335 rpm 300 rpm
4 360 rpm 325 rpm 395 rpm 360 rpm
5 445 rpm 410 rpm 470 rpm 435 rpm
6 545 rpm 510 rpm 560 rpm 525 rpm
7 660 rpm 625 rpm 660 rpm 625 rpm
8 850 rpm 815 rpm 842 rpm 807 rpm
Cooling Heating
Step M1F M2F M1F M2F
0 0 rpm 0 rpm 0 rpm 0 rpm
1 250 rpm 0 rpm 250 rpm 0 rpm
2 400 rpm 0 rpm 285 rpm 250 rpm
3 285 rpm 250 rpm 335 rpm 300 rpm
4 360 rpm 325 rpm 395 rpm 360 rpm
5 445 rpm 410 rpm 470 rpm 435 rpm
6 545 rpm 510 rpm 560 rpm 525 rpm
7 660 rpm 625 rpm 660 rpm 625 rpm
8 827 rpm 792 rpm 832 rpm 797 rpm
