Outdoor Unit Functional Concept SiBE27-702
70 Functional Description
3.2 Function Outline in Heating Mode
Flow chart Heating operation
*1 Only for Trank Shaped : RZQ100~140C7, RZQS125·140C7V1B (1 phase) and
RZQ100~140B8W1B (3 phase).
*2 Only for B Series : RZQ71B9, RZQS71·100B7V3B (1 phase) and RZQ100~140B8W1B (3
phase).
Power supply ON
Initialize motorized valve
Initialize microcomputer
Crank case heater control *1
Preheating operation control
Remote controller ON
operation judgement
Operation mode
judgement
Cooling/Dry
Heating
Emergency
operation
Thermostat ON judgement
Starting control
4-way valve changeover
Hot start control
Compressor step control
Motorized valve PI control
PMV control
Low pressure protection control
High pressure protection control
Heating overload control
Discharge pipe temperature protection control
Inverter current protection control
Inverter fin temperature protection control
Overall current protection control
Suction pipe superheat degree protection control
Simulated operation
Normal control
Defrosting
condition
Defrost
operation
Defrost
ending
judgement
Hot start
control
Remote
control
operation OFF
judgement
Standby
judgement
Malfunction
stop
judgement
Thermostat OFF judgement
Thermostat OFF by <
∆
> Tr
Thermostat OFF by outdoor
temperature
Pump down residual operation *2
Restart standby
A
B
B
A
Cooling/Dry Emergency
Malfunction
code
indication
4-way valve
changeover
Heating
4-way valve
changeover
Turn on the power to crankcase heater *1
