SiBE27-702 Troubleshooting by Remote Controller Display / LED Display
Troubleshooting 175
Troubleshooting
Are float
switch and drain
pipe normal?
Is water
drainage system
normal?
Is drain-up
kit installed?
Is drain pump
normal?
Does drain
water flow in
reverse during non
operation?
Is
amount
of circulated drain
water excessive after
pump stops
operation?
YES
YES
YES
YES
YES
YES
NO
NO
NO
NO
NO
∗ In FHQ and FAQ problems can also
occur in the optional drain-up kit.
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Possible failure of float
switch. Check to see if drain-
up height and horizontal pipe
length exceed specifications.
Clogged drain water
discharge system
Clogged drain pump
Faulty float switch
Replace indoor unit PC board.
Check to see if drain-up
height and horizontal pipe
length exceed specifications.
Check water drainage
system.
Check to see if drain-up
height and horizontal pipe
length exceed specifications.
Faulty trap in water
drainage system
Replace indoor unit PC
board.
Check jumper connector
X15A.
Check drain pump and
drain pipe.
NO
