5-26
Chapter 5: BIOS Setup
SATA Port 1-8
Port 1-8
Allows you to enable or disable the SATA port.
Congurationoptions:[Disabled][Enabled]
PCHsSATAConguration
sSATA Controller [Enabled]
Allows you to enable or disable the sSATA Controller.
Congurationoptions:[Disabled][Enabled]
Configure sSATA as [AHCI]
AllowsyoutoidentifytheSATAportconnectedtoSolidStateDriveorHardDiskDrive.
Congurationoptions:[IDE][AHCI][RAID]
Support Aggressive Link Power Management [Enabled]
AllowsyoutoenableordisabletheSupportAggressiveLinkPower(SALP)
Management.
Congurationoptions:[Disabled][Enabled]
sSATA Port 1-3
Port 1-3
Allows you to enable or disable the SATA port.
Congurationoptions:[Disabled][Enabled]
USBConguration
USB Precondition [Disabled]
AllowsyoutoenableordisablepreconditionworkonUSBhostcontrollerandrootports
for faster enumeration.
Congurationoptions:[Disabled][Enabled]
XHCI Manual Mode [Disabled]
This option is used by validation.
Congurationoptions:[Disabled][Enabled]
The following items appears only when the XHCI Manual Mode is set to [Enabled].
Trunk Clock Gating (BTCG) [Enabled]
Allows you to enable or disable BTCG.
Congurationoptions:[Disabled][Enabled]
Enable USB 3.0 pins [Disable all pins]
Allows you to enable or disable USB 3.0 pins or on a per pin basis.
Congurationoptions:[SelectPer-Pin][Disableallpins][Enableallpins]
USB Per-Connector Disable [Disabled]
Allows you to enable or disable each of the USB physical connectors. Once a
connectorisdisabled,anyUSBdevicespluggedintotheconnectorwillnotbedetected
by BIOS or OS.
Congurationoptions:[Disabled][Enabled]
