Chapter 3: Installation Options
3-8
3.2 Cable management arm
(optional for 1200 mm rack rails)
Youcaninstallanadditionalcablemanagementarm(CMA)totherackrailstohelpyou
managethecablesfromyourserversystem.TheCMAisdesignedwithmovablepartsthat
allowyoutomovetheserversystemalongtherackrailwithouttheneedtoremovetheCMA.
3.2.1 Attaching the cable management arm
Installing the cable management arm
To install the cable management arm:
1. Installtherackrailsintotherack.
Refertosection3.1 Rail Kit forthestepsoninstallingtherackrailsintotherack.
2. Presstheroundbuttononthepivotreceptor,thenrotatethepivotreceptortotheleftor
rightforaleftpivotcongurationorrightpivotconguration.
Outer receptor
Inner receptor
Pivot receptor
RightpivotcongurationLeftpivotconguration
Cable fasteners
Hook and loop fasteners
