Chapter 1: Product Introduction
1-6
Systemspecications
Model Name ESC4000 G4 ESC4000 G4X ESC4000 G4S
Networking
LAN
1 x Dual Port Intel
®
I350-AM2 Gigabit LAN controller
1 x Management Port
Inniband
Optional PEM-FDR
Graphic
VGA
Aspeed AST2500 64MB
Front I/O ports
1 x 80port
2 x USB 2.0 ports + 2 x USB 3.0 port
Rear I/O
2 x USB 3.0 port
1 x VGA port
1 x RJ-45 Mgmt LAN port
2 x RJ-45 GbE LAN ports
Switch/LED
Rear Switch/LED:
1 x Power switch/LED
1 x Location LED
1 x Message LED
1 x Storage Device Access LED
Front Switch/LED:
1 x Power switch/LED
1 x Location switch/LED
1 x Storage Device Access LED
1 x Message LED
2 x LAN LED
OS Support
Please nd the latest OS support from http://www.asus.com/
(continued on the next page)
