Chapter 3: Installation Options
3-6
1
2
9. Aligntheserversystemandgently
insert it into the rack rails.
Intermediate railInner rail
11. Gentlypushtheserversystemuntilitiscompletelyinstalledintotherackrail.
(optional)For1200mmrackrails,iftheinnerrailclickstoastopwhileyouareinstalling
theserversystemintotherackrails,slidethebluereleasetaboutwardsandgently
pushtheserversystemuntilitiscompletelyinstalledintotherackrail.
10. (optional)UsetheM5X20Lscrewsto
secure the rack rails to the rack post.
Front end of rack rail
Front rack post
Blue release tab White release tab
Thebluereleasetabisavailableon1200mmrackrails.Thisbluereleasetabisusedto
furtherextendorretracttheinnerrail.
