SiBE04-705 Troubleshooting
Service Diagnosis 117
4. Troubleshooting
4.1 Error Codes and Description
+
: Displayed only when system-down occurs.
Code Indication Description
Reference
Page
System
00
Normal
—
U0+
Insufficient gas
150
U2
Low-voltage detection or over-voltage detection
152
U4
Signal transmission error (between indoor and outdoor units)
124
Indoor
Unit
A1
Indoor unit PCB abnormality
118
A5
Freeze-up protection control or high pressure control
119
A6
Fan motor or related abnormality
121
C4
Heat exchanger thermistor abnormality
123
C9
Room temperature thermistor abnormality
123
Outdoor
Unit
E1
Outdoor unit PCB abnormality
126
E5+
OL activation (compressor overload)
127
E6+
Compressor lock
128
E7
DC fan lock
129
E8
Input over current detection
130
EA
Four Way Valve Abnormality
132
F3
Discharge pipe temperature control
134
F6
High Pressure Control in Cooling
135
H0
Sensor abnormality
137
H6
Position sensor abnormality
139
H8
CT or related abnormality
140
H9
Outdoor air thermistor or related abnormality
142
J3
Discharge pipe thermistor or related abnormality
142
J6
Heat exchanger thermistor or related abnormality
142
L3
Electrical box temperature rise
144
L4
Radiation fin temperature rise
146
L5
Output over current detection
148
P4
Radiation fin thermistor or related abnormality
142
U7
Signal transmission error
153
