SiBE04-705 Specifications
Specifications 13
50Hz 220-230-240V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Units FTXS50FV1B FTXS60FV1B
Outdoor Units
RXS50F2V1B RXS60F2V1B
Cooling Heating Cooling Heating
Capacity
Rated (Min.~Max.)
kW 5.0 (1.7~6.0) 5.8 (1.7~7.7) 6.0 (1.7~6.7) 7.0 (1.7~8.0)
Btu/h 17,100 (5,800~20,500) 19,800 (5,800~26,300) 20,500 (5,800~22,900) 23,900 (5,800~27,300)
kcal/h 4,300 (1,460~5,160) 4,990 (1,460~6,620) 5,160 (1,460~5,760) 6,020 (1,460~6,880)
Running Current
Rated
A 7.2-6.9-6.6 7.4-7.1-6.8 9.2-8.8-8.4 9.4-9.0-8.6
Power Consumption
Rated (Min.~Max.)
W 1,550 (440~2,080) 1,600 (400~2,530) 1,990 (440~2,400) 2,040 (400~2,810)
Power Factor % 97.9-97.7-97.9 98.3-98.0-98.0 98.3-98.3-98.7 98.6-98.6-98.8
COP
Rated (Min.~Max.)
W/W 3.23 (3.86~2.88) 3.63 (4.25~3.04) 3.02 (3.86~2.79) 3.43 (4.25~2.85)
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Unit FTXS50FV1B FTXS60FV1B
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 14.7 (519) 16.1 (569) 16.2 (572) 17.4 (614)
M 12.4 (438) 13.9 (491) 13.6 (480) 15.1 (533)
L 10.3 (364) 11.5 (406) 11.4 (403) 12.7 (448)
SL 9.5 (335) 10.2 (360) 10.2 (360) 11.4 (403)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Quiet, Auto 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.16-0.15-0.15 0.17-0.16-0.16 0.19-0.18-0.17 0.21-0.20-0.19
Power Consumption (Rated) W 34 36 40 45
Power Factor % 96.6-98.6-94.4 96.3-97.8-93.8 95.7-96.6-98.0 97.4-97.8-98.7
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 43 / 39 / 34 / 31 42 / 38 / 33 / 30 45 / 41 / 36 / 33 44 / 40 / 35 / 32
Sound Power dBA 59 58 61 60
Outdoor Unit RXS50F2V1B RXS60F2V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant
Oil
Model FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant
Model R-410A R-410A
Charge kg 1.50 1.50
Air Flow Rate m³/min (cfm)
HH 50.9 (1,797) — 54.2 (1,914) —
H 48.9 (1,727) 45.0 (1,589) 50.9 (1,797) 46.3 (1,635)
L 41.7 (1,472) 45.0 (1,589) 45.0 (1,589) 46.3 (1,635)
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 7.04-6.75-6.45 7.23-6.94-6.64 9.01-8.62-8.23 9.19-8.80-8.41
Power Consumption (Rated) W 1,516 1,564 1,950 1,995
Power Factor (Rated) % 97.9-97.6-97.9 98.3-98.0-98.1 98.4-98.4-98.7 98.7-98.6-98.8
Starting Current A 7.4 9.4
Dimensions (H×W×D) mm 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 797×960×390 797×960×390
Weight kg 48 48
Gross Weight kg 53 53
Operation
Sound
H/L dBA 47 / 44 48 / 45 49 / 46 49 / 46
Sound Power H dBA 61 62 63 63
Drawing No. 3D056019 3D056020
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
