Daikin RYN60E3V1B [262/300] Removal of the electrical box
![Daikin RYN60E3V1B [262/300] Removal of the electrical box](/views2/1776922/page262/bg106.png)
SiBE04-705 Outdoor Unit
Removal Procedure 251
2.2.2 Removal of the Electrical Box
Procedure Warning Be sure to wait 10 minutes or more after turning off all power supplies
before disassembling work.
Step Procedure Points
1 Remove the fixing
screw from the shut-off
valve mounting plate.
2 Remove the fixing
screw on the partition
plate.
3 Remove the 2 screws
to detach the earth
wires.
(
R7005
)
(R7006)
(R7007)
