Specifications SiBE04-705
14 Specifications
50Hz 220-230-240V
Note:
The data are based on the conditions shown in the table below.
Model
Indoor Units FTXS71FV1B
Outdoor Units
RXS71FV1B
Cooling Heating
Capacity
Rated (Min.~Max.)
kW 7.1 (2.3~8.5) 8.2 (2.3~10.2)
Btu/h 24,200 (7,800~29,000) 28,000 (7,800~34,800)
kcal/h 6,110 (1,980~7,310) 7,050 (1,980~8,770)
Running Current
Rated
A 10.8-10.4-9.9 11.7-11.2-10.7
Power Consumption
Rated (Min.~Max.)
W 2,350 (570~3,200) 2,550 (520~3,820)
Power Factor % 98.9-98.2-98.9 99.1-99.0-99.3
COP
Rated (Min.~Max.)
W/W 3.02 (4.04~2.66) 3.22 (4.42~2.67)
Piping
Connections
Liquid mm
φ
6.4
Gas mm
φ
15.9
Drain mm
φ
18.0
Heat Insulation Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30
Max. Interunit Height Difference m 20
Chargeless m 10
Amount of Additional Charge of
Refrigerant
g/m 20
Indoor Unit FTXS71FV1B
Front Panel Color White
Air Flow Rate
m³/min
(cfm)
H 17.4 (614) 19.7 (696)
M 14.6 (516) 16.9 (597)
L 11.6 (410) 14.3 (505)
SL 10.6 (374) 12.7 (448)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Quiet, Auto
Air Direction Control Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof
Running Current (Rated) A 0.21-0.20-0.19 0.28-0.27-0.26
Power Consumption (Rated) W 45 60
Power Factor % 97.4-97.8-98.7 97.4-96.6-96.2
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46 / 42 / 37 / 34 46 / 42 / 37 / 34
Sound Power dBA 62 62
Outdoor Unit RXS71FV1B
Casing Color Ivory White
Compressor
Type Hermetically Sealed Swing Type
Model 2YC63BXD
Motor Output W 1,920
Refrigerant
Oil
Model FVC50K
Charge L 0.75
Refrigerant
Model R-410A
Charge kg 2.30
Air Flow Rate m³/min (cfm)
HH 57.1 (2,016) —
H 54.5 (1,924) 52.5 (1,854)
L 46.0 (1,624) 46.0 (1,624)
Fan
Type Propeller
Motor Output W 66
Running Current (Rated) A 10.59-10.20-9.71 11.42-10.93-10.44
Power Consumption (Rated) W 2,305 2,490
Power Factor (Rated) % 98.9-98.3-98.9 99.1-99.0-99.4
Starting Current A 11.7
Dimensions (H×W×D) mm 770×900×320
Packaged Dimensions (H×W×D) mm 900×925×390
Weight kg 71
Gross Weight kg 78
Operation
Sound
H/L dBA 52 / 49 52 / 49
Sound Power H dBA 66 66
Drawing No. 3D056021
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Heating Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
Indoor ; 20°CDB
Outdoor ; 7°CDB/6°CWB
7.5m
