SiBE04-705 Specifications
Specifications 11
50Hz 220-230-240V
Note:
The data are based on the conditions shown in the table below.
Models
Indoor Units FTN50FV1B FTN60FV1B
Outdoor Units RN50E3V1B RN60E3V1B
Capacity
Rated
kW 5.0 6.0
Btu/h 17,100 20,500
kcal/h 4,300 5,160
Running Current (Rated) A 7.2-6.9-6.6 9.2-8.8-8.4
Power Consumption
Rated
W 1,550 1,990
Power Factor % 97.9-97.7-97.9 98.3-98.3-98.7
COP (Rated) W/W 3.23 3.02
Piping
Connections
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
12.7
Drain mm
φ
18.0
φ
18.0
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Max. Interunit Piping Length m 30 30
Max. Interunit Height Difference m 20 20
Chargeless m 10 10
Amount of Additional Charge of
Refrigerant
g/m 20 20
Indoor Units FTN50FV1B FTN60FV1B
Front Panel Color White White
Air Flow Rate
m³/min
(cfm)
H 14.7 (519) 16.2 (572)
M 12.4 (438) 13.6 (480)
L 10.3 (364) 11.4 (403)
SL — —
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Auto 5 Steps, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable / Washable / Mildew Proof Removable / Washable / Mildew Proof
Running Current (Rated) A 0.16-0.15-0.15 0.19-0.18-0.17
Power Consumption (Rated) W 34 40
Power Factor % 96.6-98.6-94.4 95.7-96.6-98.0
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/L dBA 43 / 34 45 / 36
Sound Power dBA 59 61
Outdoor Units RN50E3V1B RN60E3V1B
Casing Color Ivory White Ivory White
Compressor
Type Hermetically Sealed Swing Type Hermetically Sealed Swing Type
Model 2YC36BXD 2YC36BXD
Motor Output W 1,100 1,100
Refrigerant
Oil
Type FVC50K FVC50K
Charge L 0.65 0.65
Refrigerant
Type R-410A R-410A
Charge kg 1.50 1.50
Air Flow Rate
m³/min
(cfm)
HH 50.9 (1,797) 54.2 (1,914)
H 48.9 (1,727) 50.9 (1,797)
L 41.7 (1,472) 45.0 (1,589)
Fan
Type Propeller Propeller
Motor Output W 53 53
Running Current (Rated) A 7.04-6.75-6.45 9.01-8.62-8.23
Power Consumption (Rated) W 1,516 1,950
Power Factor % 97.9-97.6-97.9 98.4-98.4-98.7
Starting Current A 7.2 9.2
Dimensions (H×W×D) mm 735×825×300 735×825×300
Packaged Dimensions (H×W×D) mm 797×960×390 797×960×390
Weight kg 47 47
Gross Weight kg 52 52
Operation
Sound
HdBA 47 49
Sound Power H dBA 61 63
Drawing No. 3D056022 3D056023
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Cooling Piping Length
Indoor ; 27°CDB/19°CWB
Outdoor ; 35°CDB/24°CWB
7.5m
