SiBE04-705 Outdoor Unit
Removal Procedure 219
3
Unscrew the washer-
fitted nut (M10) of the
propeller fan with a
spanner.
Align mark of the
propeller fan with D-cut
section of the motor shaft
when reassembling.
4
Remove the 4 screws
from the fan motor.
Step
Procedure Points
