Daikin CDX25AVMA [103/268] Super multi nx b series heat pump
![Daikin CDX35AVMA [103/268] Super multi nx b series heat pump](/views2/1761711/page103/bg67.png)
Capacity Tables ED12-321A
98 SUPER MULTI NX B-Series Heat Pump
3D042742#5
3D042742#6
[Heating Capacity 220V 50 / 60Hz]
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5+3.5+3.5 22 6.941.857.372.057.792.098.012.108.652.149.082.16
25 6.68 2.17 7.11 2.22 7.54 2.25 7.75 2.26 8.39 2.31 8.82 2.34
32 6.32 2.40 6.75 2.47 7.17 2.52 7.39 2.54 8.03 2.61 8.45 2.66
35 6.16 2.52 6.59 2.58 7.02 2.65
7.23 2.68 7.87 2.75 8.30 2.80
40 5.90 2.71 6.33 2.80 6.76 2.88 6.97 2.91 7.61 3.01 8.04 3.07
43 5.75 2.85 6.17 2.93 6.60 3.02 6.81 3.06 7.46 3.17 7.88 3.24
46 5.59 2.98 6.01 3.00 6.41 3.00 6.60 3.00 7.16 3.00 7.53 3.00
2.5+3.5+5.0 22 7.111.807.552.007.992.038.212.058.862.089.302.10
25 6.85 2.12 7.29 2.16 7.72 2.19 7.94 2.20 8.60 2.25 9.04 2.28
32 6.48 2.34 6.91 2.40 7.35 2.45 7.57 2.48 8.23 2.54 8.66 2.59
35 6.32 2.45 6.75 2.51 7.19 2.58
7.41 2.61 8.07 2.68 8.50 2.73
40 6.05 2.64 6.49 2.73 6.93 2.80 7.14 2.84 7.80 2.93 8.24 2.99
43 5.89 2.78 6.33 2.86 6.77 2.94 6.98 2.98 7.64 3.09 8.08 3.15
46 5.73 2.91 6.17 3.00 6.57 3.00 6.77 3.00 7.34 3.00 7.72 3.00
3.5+3.5+3.5 22 7.091.917.522.137.962.178.172.188.832.229.262.24
25 6.82 2.25 7.26 2.30 7.69 2.33 7.91 2.35 8.56 2.40 9.00 2.42
32 6.45 2.49 6.89 2.56 7.32 2.61 7.54 2.64 8.19 2.71 8.63 2.76
35 6.29 2.61 6.73 2.68 7.16 2.75
7.38 2.78 8.03 2.86 8.47 2.90
40 6.03 2.81 6.46 2.90 6.90 2.99 7.12 3.02 7.77 3.13 8.20 3.18
43 5.87 2.96 6.30 3.04 6.74 3.13 6.96 3.18 7.61 3.29 8.05 3.36
46 5.70 3.00 6.11 3.00 6.52 3.00 6.72 3.00 7.28 3.00 7.65 3.00
Symbols NOTES:
TC : Total capacity (kW) Capacities are based on the following conditions.
Corresponding refrigerant piping length : 7.5m
Level difference : 0m
PI : Power input (kW)
Combination
(Capacity)
Indoor
Air Temp.
°CDB
Outdoor Air Temp.:°CWB
-15 -10 -5 0 6 10 15
TC PI TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW kW kW
2.5 16 2.76 1.28 3.23 1.37 3.75 1.47 4.21 1.55 4.79 1.64 5.03 1.62 5.03 1.45
18 2.74 1.32 3.22 1.42 3.74 1.51 4.19 1.59 4.77 1.68 5.01 1.66 5.01 1.49
20 2.73 1.36 3.21 1.46 3.73 1.55 4.17 1.63
4.75 1.73 4.99 1.71 4.99 1.53
21 2.73 1.38 3.21 1.48 3.72 1.57 4.17 1.65 4.74 1.75 4.98 1.73 4.98 1.55
22 2.72 1.40 3.20 1.50 3.72 1.59 4.16 1.67 4.66 1.74 4.66 1.59 4.66 1.43
24 2.71 1.44 3.19 1.54 3.71 1.64 4.02 1.63 4.02 1.42 4.02 1.30 4.02 1.18
3.5 16 3.13 1.58 3.67 1.69 4.26 1.82 4.78 1.90 5.45 2.02 5.92 2.10 6.11 1.97
18 3.12 1.63 3.66 1.74 4.25 1.86 4.76 1.95 5.42 2.07 5.81 2.11 5.81 1.87
20 3.11 1.68 3.65 1.79 4.24 1.91 4.75 2.00
5.40 2.13 5.49 1.97 5.49 1.75
21 3.10 1.70 3.64 1.82 4.23 1.94 4.74 2.03 5.34 2.12 5.34 1.91 5.34 1.70
22 3.10 1.73 3.64 1.84 4.23 1.96 4.73 2.06 5.19 2.05 5.19 1.85 5.19 1.65
24 3.08 1.78 3.63 1.90 4.21 2.02 4.71 2.12 4.88 1.92 4.88 1.72 4.88 1.54
5.0 16 4.29 2.09 5.03 2.24 5.84 2.40 6.55 2.52 7.47 2.67 8.11 2.78 8.94 2.93
18 4.28 2.15 5.02 2.31 5.82 2.46 6.53 2.58 7.43 2.74 8.07 2.86 8.89 3.01
20 4.26 2.22 5.00 2.38 5.81 2.53 6.50 2.65
7.40 2.82 8.03 2.94 8.85 3.10
21 4.25 2.25 4.99 2.41 5.80 2.56 6.49 2.69 7.38 2.86 8.01 2.98 8.83 3.14
22 4.24 2.29 4.99 2.44 5.79 2.60 6.48 2.73 7.37 2.90 7.99 3.02 8.81 3.19
24 4.23 2.36 4.97 2.51 5.78 2.67 6.46 2.81 7.34 2.99 7.96 3.11 8.34 2.95
6.0 16 4.84 2.46 5.68 2.64 6.59 2.83 7.40 2.97 8.43 3.15 9.15 3.28 10.08 3.45
18 4.82 2.54 5.66 2.72 6.57 2.90 7.37 3.04 8.39 3.23 9.10 3.37 10.03 3.55
20 4.81 2.61 5.64 2.80 6.55 2.98 7.34 3.12
8.35 3.32 9.06 3.46 9.98 3.65
21 4.80 2.65 5.64 2.84 6.54 3.02 7.32 3.17 8.33 3.37 9.04 3.51 9.96 3.70
22 4.79 2.69 5.63 2.88 6.53 3.06 7.31 3.21 8.31 3.42 9.02 3.56 9.94 3.76
24 4.77 2.77 5.61 2.95 6.52 3.15 7.29 3.31 8.28 3.52 8.98 3.67 9.40 3.43
2.5+2.5 16 4.61 2.24 5.41 2.41 6.28 2.58 7.04 2.71 8.02 2.87 8.71 2.99 9.60 3.15
18 4.59 2.31 5.39 2.48 6.26 2.65 7.01 2.78 7.99 2.95 8.67 3.07 9.55 3.24
20 4.58 2.39 5.37 2.55 6.24 2.72 6.99 2.85
9.40 3.44 8.63 3.16 9.45 3.28
21 4.57 2.42 5.37 2.59 6.23 2.75 6.97 2.89 7.93 3.07 8.61 3.20 9.40 3.32
22 4.56 2.46 5.36 2.62 6.22 2.79 6.96 2.93 7.92 3.12 8.55 3.22 8.55 2.75
24 4.54 2.53 5.34 2.70 6.20 2.87 6.94 3.02 7.88 3.21 8.04 2.93 8.04 2.51
