ED12-321A Indoor Units
Installation Manual 143
4
Intelligent-eye
sensor
1. Adjusting the angle
1) Once installation of the indoor unit is complete,
adjust the angle of the Intelligent-eye sensor to
ensure the detection area properly covers the room.
(Adjustable angle: 15° to right and left of centre)
2) Gently push and slide the sensor to adjust the
angle. Aim so that the sensor is pointing to the
centre of the room, or to the part of the room that is
most frequently used.
3) After adjusting the angle, gently wipe the sensor
with a clean cloth, being careful not to scratch the
sensor.
15° 15°
Moving the sensor to the left Moving the sensor to the right
Intelligent-Eye Sensor
1) Do not hit or violently push the Intelligent-eye
sensor. This can lead to damage and
malfunction.
2) Do not place large objects near the sensor. Also
keep heating units or humidifiers outside the
sensor’s detection area.
Caution
