Daikin CDX25AVMA [123/268] Super multi nx b series heat pump
![Daikin CDX25AVMA [123/268] Super multi nx b series heat pump](/views2/1761711/page123/bg7b.png)
Capacity Tables ED12-321A
118 SUPER MULTI NX B-Series Heat Pump
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
6.0+7.1 22 8.12 2.35 8.62 2.61 9.12 2.66 9.37 2.67 10.12 2.72 10.62 2.75
25 7.82 2.77 8.32 2.82 8.82 2.86 9.07 2.88 9.82 2.94 10.32 2.97
32 7.39 3.06 7.89 3.14 8.39 3.20 8.64 3.24 9.39 3.32 9.89 3.38
35 7.21 3.20 7.71 3.28 8.21 3.37
8.46 3.41 9.21 3.50 9.71 3.56
40 6.91 3.45 7.41 3.56 7.91 3.66 8.16 3.71 8.91 3.83 9.41 3.90
43 6.73 3.54 7.21 3.54 7.67 3.54 7.90 3.54 8.59 3.54 9.04 3.54
46 6.39 3.23 6.81 3.23 7.22 3.23 7.41 3.23 8.01 3.23 8.41 3.23
2.5+2.5+2.5 22 7.231.907.672.128.122.158.342.169.012.209.452.22
25 6.96 2.24 7.40 2.28 7.85 2.32 8.07 2.33 8.74 2.38 9.18 2.41
32 6.58 2.48 7.03 2.54 7.47 2.59 7.69 2.62 8.36 2.69 8.80 2.74
35 6.42 2.59 6.86 2.66 7.31 2.73
7.53 2.76 8.20 2.84 8.64 2.88
40 6.15 2.79 6.59 2.88 7.04 2.96 7.26 3.00 7.93 3.10 8.37 3.16
43 5.99 2.94 6.43 3.02 6.88 3.11 7.10 3.15 7.76 3.27 8.21 3.33
46 5.82 3.07 6.27 3.19 6.70 3.23 6.92 3.23 7.54 3.23 7.94 3.23
2.5+2.5+3.5 22 7.602.118.072.358.542.388.772.409.472.449.942.47
25 7.32 2.48 7.79 2.53 8.25 2.57 8.49 2.59 9.19 2.64 9.66 2.67
32 6.92 2.75 7.39 2.82 7.86 2.87 8.09 2.90 8.79 2.98 9.26 3.04
35 6.75 2.87 7.22 2.95 7.69 3.02
7.92 3.06 8.62 3.14 9.09 3.20
40 6.47 3.10 6.93 3.20 7.40 3.29 7.64 3.33 8.34 3.44 8.80 3.50
43 6.30 3.26 6.76 3.35 7.23 3.45 7.47 3.50 8.16 3.54 8.60 3.54
46 6.11 3.23 6.54 3.23 6.97 3.23 7.17 3.23 7.79 3.23 8.19 3.23
2.5+2.5+5.0 22 7.84 2.03 8.33 2.26 8.81 2.30 9.05 2.31 9.77 2.36 10.26 2.38
25 7.55 2.39 8.03 2.44 8.52 2.48 8.76 2.49 9.48 2.54 9.96 2.57
32 7.14 2.65 7.62 2.71 8.10 2.77 8.35 2.80 9.07 2.87 9.55 2.93
35 6.96 2.77 7.45 2.84 7.93 2.92
8.17 2.95 8.89 3.03 9.38 3.08
40 6.67 2.98 7.15 3.08 7.64 3.17 7.88 3.21 8.60 3.32 9.08 3.38
43 6.50 3.14 6.98 3.23 7.46 3.32 7.70 3.37 8.42 3.49 8.90 3.54
46 6.32 3.23 6.78 3.23 7.23 3.23 7.46 3.23 8.11 3.23 8.52 3.23
2.5+2.5+6.0 22 8.27 2.18 8.77 2.43 9.28 2.47 9.54 2.49 10.30 2.53 10.81 2.55
25 7.96 2.57 8.47 2.62 8.97 2.66 9.23 2.68 9.99 2.73 10.50 2.76
32 7.52 2.84 8.03 2.92 8.54 2.98 8.80 3.01 9.56 3.09 10.07 3.14
35 7.34 2.98 7.85 3.05 8.36 3.13
8.61 3.17 9.37 3.26 9.88 3.31
40 7.03 3.21 7.54 3.31 8.05 3.40 8.30 3.45 9.06 3.56 9.57 3.63
43 6.85 3.38 7.35 3.47 7.86 3.54 8.11 3.54 8.83 3.54 9.29 3.54
46 6.61 3.23 7.07 3.23 7.52 3.23 7.73 3.23 8.37 3.23 8.80 3.23
2.5+2.5+7.1 22 8.31 2.30 8.83 2.56 9.34 2.60 9.59 2.62 10.36 2.67 10.87 2.69
25 8.00 2.71 8.51 2.76 9.03 2.80 9.28 2.82 10.05 2.88 10.56 2.91
32 7.57 3.00 8.08 3.07 8.59 3.14 8.85 3.17 9.61 3.25 10.12 3.31
35 7.38 3.13 7.89 3.22 8.40 3.30
8.66 3.34 9.43 3.43 9.94 3.49
40 7.07 3.38 7.58 3.49 8.09 3.59 8.35 3.63 9.12 3.76 9.63 3.82
43 6.88 3.54 7.39 3.54 7.88 3.54 8.12 3.54 8.83 3.54 9.30 3.54
46 6.58 3.23 7.02 3.23 7.45 3.23 7.65 3.23 8.27 3.23 8.68 3.23
2.5+3.5+3.5 22 7.70 2.16 8.17 2.40 8.65 2.44 8.88 2.45 9.59 2.50 10.07 2.52
25 7.41 2.54 7.89 2.59 8.36 2.63 8.60 2.64 9.31 2.70 9.78 2.73
32 7.01 2.81 7.48 2.88 7.96 2.94 8.19 2.97 8.90 3.05 9.38 3.10
35 6.84 2.94 7.31 3.01 7.78 3.09
8.02 3.13 8.73 3.22 9.20 3.27
40 6.55 3.17 7.02 3.27 7.50 3.36 7.73 3.40 8.44 3.52 8.92 3.58
43 6.38 3.33 6.85 3.42 7.32 3.53 7.56 3.54 8.25 3.54 8.69 3.54
46 6.17 3.23 6.60 3.23 7.02 3.23 7.22 3.23 7.83 3.23 8.23 3.23
2.5+3.5+5.0 22 8.27 2.18 8.77 2.43 9.28 2.47 9.54 2.49 10.30 2.53 10.81 2.55
25 7.96 2.57 8.47 2.62 8.97 2.66 9.23 2.68 9.99 2.73 10.50 2.76
32 7.52 2.84 8.03 2.92 8.54 2.98 8.80 3.01 9.56 3.09 10.07 3.14
35 7.34 2.98 7.85 3.05 8.36 3.13
8.61 3.17 9.37 3.26 9.88 3.31
40 7.03 3.21 7.54 3.31 8.05 3.40 8.30 3.45 9.06 3.56 9.57 3.63
43 6.85 3.38 7.35 3.47 7.86 3.54 8.11 3.54 8.83 3.54 9.29 3.54
46 6.61 3.23 7.07 3.23 7.52 3.23 7.73 3.23 8.37 3.23 8.80 3.23
2.5+3.5+6.0 22 8.29 2.18 8.80 2.42 9.31 2.46 9.57 2.48 10.34 2.52 10.85 2.55
25 7.98 2.56 8.49 2.61 9.00 2.65 9.26 2.67 10.03 2.72 10.54 2.76
32 7.55 2.84 8.06 2.91 8.57 2.97 8.83 3.00 9.59 3.08 10.10 3.13
35 7.36 2.97 7.87 3.04 8.38 3.12
8.64 3.16 9.41 3.25 9.92 3.30
40 7.05 3.20 7.56 3.30 8.07 3.39 8.33 3.44 9.10 3.55 9.61 3.62
43 6.87 3.37 7.38 3.46 7.89 3.54 8.13 3.54 8.86 3.54 9.32 3.54
46 6.63 3.23 7.09 3.23 7.54 3.23 7.76 3.23 8.40 3.23 8.84 3.23
