ED12-321A Capacity Tables
SUPER MULTI NX B-Series Cooling Only 55
2
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5+6.0+6.0 22 8.93 2.09 9.48 2.33 10.03 2.37 10.30 2.38 11.12 2.43 11.67 2.45
25 8.59 2.47 9.14 2.51 9.69 2.55 9.97 2.57 10.79 2.62 11.34 2.65
32 8.13 2.73 8.68 2.80 9.23 2.86 9.50 2.88 10.32 2.96 10.87 3.02
35 7.93 2.85 8.48 2.93 9.03 3.00
9.30 3.04 10.12 3.12 10.67 3.18
40 7.59 3.08 8.14 3.18 8.69 3.27 8.97 3.30 9.79 3.42 10.34 3.48
43 7.39 3.24 7.94 3.33 8.49 3.42 8.77 3.47 9.57 3.57 10.08 3.57
46 7.06 2.99 7.52 2.99 7.97 2.99 8.20 2.99 8.83 2.99 9.25 2.99
3.5+3.5+3.5 22 8.16 2.23 8.66 2.48 9.16 2.52 9.41 2.54 10.17 2.59 10.67 2.61
25 7.86 2.63 8.36 2.68 8.86 2.72 9.11 2.74 9.86 2.79 10.36 2.83
32 7.43 2.91 7.93 2.98 8.43 3.04 8.68 3.07 9.44 3.15 9.94 3.21
35 7.25 3.04 7.75 3.12 8.25 3.20
8.50 3.24 9.25 3.33 9.75 3.38
40 6.94 3.28 7.44 3.38 7.94 3.48 8.20 3.52 8.95 3.64 9.45 3.71
43 6.76 3.45 7.26 3.55 7.76 3.57 8.00 3.57 8.72 3.57 9.19 3.57
46 6.38 2.99 6.79 2.99 7.19 2.99 7.38 2.99 7.96 2.99 8.35 2.99
3.5+3.5+5.0 22 8.56 2.23 9.09 2.48 9.62 2.52 9.88 2.54 10.67 2.59 11.20 2.61
25 8.24 2.63 8.77 2.68 9.30 2.72 9.56 2.74 10.35 2.79 10.88 2.83
32 7.80 2.91 8.32 2.98 8.85 3.04 9.11 3.07 9.90 3.15 10.43 3.21
35 7.60 3.04 8.13 3.12 8.66 3.20
8.92 3.24 9.71 3.33 10.24 3.38
40 7.28 3.28 7.81 3.38 8.34 3.48 8.60 3.52 9.39 3.64 9.92 3.71
43 7.09 3.45 7.62 3.55 8.13 3.57 8.39 3.57 9.13 3.57 9.60 3.57
46 6.70 2.99 7.12 2.99 7.54 2.99 7.75 2.99 8.36 2.99 8.77 2.99
3.5+3.5+6.0 22 8.64 2.24 9.17 2.49 9.70 2.53 9.97 2.55 10.77 2.60 11.30 2.62
25 8.32 2.64 8.85 2.69 9.38 2.73 9.65 2.75 10.44 2.80 10.97 2.83
32 7.87 2.92 8.40 2.99 8.93 3.05 9.19 3.08 9.99 3.16 10.52 3.22
35 7.67 3.05 8.20 3.13 8.73 3.21
9.00 3.25 9.80 3.34 10.33 3.39
40 7.35 3.29 7.88 3.39 8.41 3.49 8.68 3.53 9.47 3.65 10.01 3.72
43 7.16 3.46 7.69 3.56 8.21 3.57 8.46 3.57 9.20 3.57 9.68 3.57
46 6.75 2.99 7.18 2.99 7.60 2.99 7.81 2.99 8.42 2.99 8.84 2.99
3.5+3.5+7.1 22 8.83 2.40 9.38 2.67 9.92 2.71 10.19 2.73 11.00 2.78 11.55 2.80
25 8.50 2.82 9.05 2.88 9.59 2.92 9.86 2.94 10.67 3.00 11.22 3.04
32 8.04 3.12 8.58 3.20 9.13 3.27 9.40 3.30 10.21 3.39 10.76 3.45
35 7.84 3.27 8.39 3.35 8.93 3.44
9.20 3.48 10.01 3.58 10.56 3.63
40 7.51 3.52 8.06 3.64 8.60 3.74 8.87 3.78 9.68 3.91 10.23 3.98
43 7.30 3.57 7.83 3.57 8.33 3.57 8.58 3.57 9.32 3.57 9.80 3.57
46 6.75 2.99 7.16 2.99 7.56 2.99 7.75 2.99 8.35 2.99 8.74 2.99
3.5+5.0+5.0 22 8.77 2.24 9.31 2.50 9.85 2.54 10.12 2.56 10.93 2.60 11.47 2.63
25 8.45 2.64 8.99 2.69 9.53 2.74 9.80 2.75 10.61 2.81 11.14 2.84
32 7.99 2.92 8.53 3.00 9.07 3.06 9.34 3.09 10.15 3.17 10.69 3.23
35 7.79 3.06 8.33 3.14 8.87 3.22
9.14 3.26 9.95 3.35 10.49 3.41
40 7.46 3.30 8.00 3.41 8.54 3.50 8.81 3.54 9.62 3.67 10.16 3.73
43 7.27 3.47 7.81 3.57 8.34 3.57 8.59 3.57 9.33 3.57 9.82 3.57
46 6.85 2.99 7.28 2.99 7.71 2.99 7.92 2.99 8.54 2.99 8.96 2.99
3.5+5.0+6.0 22 8.93 2.11 9.48 2.35 10.03 2.38 10.30 2.40 11.12 2.44 11.67 2.47
25 8.59 2.48 9.14 2.53 9.69 2.57 9.97 2.59 10.79 2.64 11.34 2.67
32 8.13 2.75 8.68 2.82 9.23 2.87 9.50 2.90 10.32 2.98 10.87 3.04
35 7.93 2.87 8.48 2.95 9.03 3.02
9.30 3.06 10.12 3.14 10.67 3.20
40 7.59 3.10 8.14 3.20 8.69 3.29 8.97 3.33 9.79 3.44 10.34 3.50
43 7.39 3.26 7.94 3.35 8.49 3.45 8.77 3.50 9.56 3.57 10.06 3.57
46 7.06 2.99 7.52 2.99 7.97 2.99 8.20 2.99 8.83 2.99 9.24 2.99
3.5+6.0+6.0 22 9.22 2.29 9.78 2.55 10.35 2.60 10.63 2.61 11.48 2.66 12.05 2.68
25 8.87 2.70 9.44 2.75 10.01 2.79 10.29 2.81 11.14 2.87 11.71 2.90
32 8.39 2.99 8.96 3.06 9.52 3.13 9.81 3.16 10.66 3.24 11.22 3.30
35 8.18 3.13 8.75 3.21 9.32 3.29
9.60 3.33 10.45 3.42 11.02 3.48
40 7.84 3.37 8.41 3.48 8.97 3.58 9.26 3.62 10.11 3.74 10.67 3.81
43 7.63 3.55 8.19 3.57 8.73 3.57 8.99 3.57 9.76 3.57 10.26 3.57
46 7.15 2.99 7.59 2.99 8.04 2.99 8.24 2.99 8.89 2.99 9.32 2.99
