Capacity Tables ED12-321A
44 SUPER MULTI NX B-Series Cooling Only
7.1.2 4MKD90BVMA
[Cooling Capacity 220V 50 / 60Hz]
Combination
(Capacity)
Outdoor
Air Temp.
°CDB
Indoor Air Temp.:°CWB
14 16 18 19 22 24
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
2.5 22 2.750.583.270.743.630.803.730.814.030.824.230.83
25 2.75 0.71 3.27 0.84 3.51 0.86 3.61 0.87 3.91 0.89 4.11 0.90
32 2.75 0.84 3.14 0.95 3.34 0.97 3.44 0.98 3.74 1.00 3.94 1.02
35 2.75 0.91 3.07 0.99 3.27 1.02
3.37 1.03 3.67 1.06 3.87 1.08
40 2.75 1.04 2.95 1.08 3.15 1.11 3.25 1.12 3.55 1.16 3.75 1.18
43 2.68 1.10 2.88 1.13 3.08 1.16 3.18 1.18 3.47 1.22 3.67 1.24
46 2.61 1.15 2.81 1.19 3.00 1.23 3.10 1.25 3.40 1.30 3.60 1.33
3.5 22 3.140.823.731.064.461.294.651.335.021.365.271.37
25 3.14 1.00 3.73 1.20 4.38 1.43 4.50 1.44 4.87 1.47 5.12 1.48
32 3.14 1.20 3.73 1.44 4.17 1.60 4.29 1.61 4.66 1.65 4.91 1.69
35 3.14 1.29 3.73 1.57 4.08 1.68
4.20 1.70 4.57 1.75 4.82 1.78
40 3.14 1.48 3.68 1.78 3.93 1.83 4.05 1.85 4.42 1.91 4.67 1.95
43 3.14 1.63 3.59 1.86 3.83 1.92 3.96 1.94 4.33 2.01 4.58 2.05
46 3.14 1.78 3.50 1.97 3.74 2.03 3.87 2.06 4.24 2.14 4.49 2.19
5.0 22 5.821.516.181.686.531.716.711.727.251.757.611.76
25 5.60 1.78 5.96 1.81 6.32 1.84 6.49 1.85 7.03 1.89 7.39 1.91
32 5.30 1.96 5.65 2.02 6.01 2.06 6.19 2.08 6.73 2.13 7.08 2.17
35 5.17 2.06 5.52 2.11 5.88 2.16
6.06 2.19 6.60 2.25 6.95 2.29
40 4.95 2.22 5.31 2.29 5.66 2.35 5.84 2.38 6.38 2.46 6.74 2.51
43 4.82 2.33 5.18 2.40 5.53 2.47 5.71 2.50 6.25 2.59 6.61 2.65
46 4.69 2.44 5.05 2.53 5.40 2.61 5.58 2.66 6.11 2.74 6.43 2.74
6.0 22 6.371.786.771.997.162.027.352.037.942.078.332.09
25 6.14 2.10 6.53 2.14 6.92 2.17 7.12 2.19 7.70 2.23 8.10 2.26
32 5.80 2.32 6.19 2.38 6.59 2.43 6.78 2.46 7.37 2.52 7.76 2.57
35 5.66 2.43 6.05 2.49 6.44 2.56
6.64 2.59 7.23 2.66 7.62 2.71
40 5.42 2.62 5.81 2.71 6.21 2.78 6.40 2.82 6.99 2.91 7.38 2.97
43 5.28 2.76 5.67 2.83 6.06 2.92 6.26 2.96 6.85 3.07 7.24 3.13
46 5.12 2.74 5.48 2.74 5.82 2.74 6.00 2.74 6.48 2.74 6.81 2.74
7.1 22 6.722.027.422.427.852.468.062.488.712.529.142.55
25 6.72 2.55 7.16 2.61 7.59 2.65 7.80 2.67 8.45 2.72 8.88 2.76
32 6.36 2.84 6.79 2.91 7.22 2.97 7.44 3.00 8.08 3.08 8.51 3.13
35 6.21 2.97 6.64 3.04 7.07 3.12
7.28 3.16 7.92 3.25 8.35 3.30
40 5.94 3.20 6.37 3.30 6.80 3.39 7.02 3.44 7.66 3.55 8.09 3.62
43 5.78 3.27 6.20 3.27 6.61 3.27 6.80 3.27 7.39 3.27 7.78 3.27
46 5.35 2.74 5.68 2.74 6.01 2.74 6.17 2.74 6.63 2.74 6.95 2.74
2.5+2.5 22 5.511.306.481.726.861.757.041.767.611.797.981.81
25 5.51 1.63 6.25 1.85 6.63 1.88 6.82 1.89 7.38 1.93 7.76 1.95
32 5.51 1.98 5.93 2.06 6.31 2.10 6.50 2.13 7.06 2.18 7.44 2.22
35 5.42 2.10 5.80 2.16 6.17 2.21
6.36 2.24 6.92 2.30 7.30 2.34
40 5.19 2.27 5.57 2.34 5.94 2.41 6.13 2.44 6.70 2.52 7.07 2.56
43 5.06 2.39 5.43 2.45 5.81 2.52 5.99 2.56 6.56 2.65 6.93 2.71
46 4.92 2.49 5.29 2.59 5.67 2.67 5.86 2.72 6.36 2.74 6.70 2.74
2.5+3.5 22 5.901.556.942.057.342.097.542.108.152.148.552.16
25 5.90 1.92 6.70 2.22 7.10 2.25 7.30 2.26 7.90 2.31 8.30 2.34
32 5.90 2.36 6.35 2.47 6.76 2.52 6.96 2.54 7.56 2.61 7.96 2.66
35 5.80 2.52 6.21 2.58 6.61 2.65
6.81 2.68 7.41 2.75 7.82 2.80
40 5.56 2.71 5.96 2.80 6.36 2.88 6.57 2.91 7.17 3.01 7.57 3.07
43 5.41 2.85 5.82 2.93 6.22 3.02 6.42 3.06 7.02 3.17 7.42 3.24
46 5.24 2.74 5.59 2.74 5.94 2.74 6.12 2.74 6.63 2.74 6.95 2.74
2.5+5.0 22 7.231.877.672.098.122.128.342.139.012.179.452.19
25 6.96 2.21 7.40 2.25 7.85 2.28 8.07 2.30 8.74 2.35 9.18 2.37
32 6.58 2.44 7.03 2.50 7.47 2.55 7.69 2.58 8.36 2.65 8.80 2.70
35 6.42 2.55 6.86 2.62 7.31 2.69
7.53 2.72 8.20 2.79 8.64 2.84
40 6.15 2.75 6.59 2.84 7.04 2.92 7.26 2.96 7.93 3.06 8.37 3.11
43 5.99 2.90 6.43 2.98 6.88 3.06 7.10 3.11 7.76 3.22 8.20 3.27
46 5.74 2.74 6.13 2.74 6.50 2.74 6.68 2.74 7.20 2.74 7.55 2.74
