13 | Troubleshooting
Installer reference guide
214
EVLQ05+08CAV3 + EHYHBH05AF + EHYHBH/X08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1F – 2020.10
Error code Detailed error code Description
C0 00 Flow sensor/switch
malfunction.
Please contact your dealer.
C4 00 Heat exchanger temperature
sensor problem.
Please contact your dealer.
CJ 02 Room temperature sensor
problem.
Please contact your dealer.
EC 00 Abnormal increase tank
temperature.
EC 04 Tank preheating
H1 00 External temperature
sensor problem.
Please contact your dealer.
HC 00 Tank temperature sensor
problem.
Please contact your dealer.
HJ 11 Boiler abnormality detection
Check boiler
Refer to boiler manual
HJ 12 Bypass valve turning error
Please contact your dealer.
U3 00 Under floor heating screed
dryout function not
completed
correctly.
U4 00 Indoor/outdoor unit
communication problem.
U5 00 User interface
communication problem.
