5 | About the units and options
Installer reference guide
29
EVLQ05+08CAV3 + EHYHBH05AF + EHYHBH/X08AF + EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1F – 2020.10
Unit detail Description
Data related to domestic hot water
Data related to space heating
Information regarding electrical power
supply (Voltage, mains frequency,
elmax, IP-class)
PMS Permissible overpressure in space
heating circuit
PWS Permissible overpressure in domestic
hot water circuit
Qn HS Input related to gross caloric value in
kilowatts
Qn Hi Input related to net caloric value in
kilowatts
Pn Output in kilowatts
DE, FR, GB, IT, NL Countries of Destination (EN437)
I2E(s), I2H, IIELL3P, II2H3P, II2Esi3P Approved unit categories (EN437)
G20-20mbar
G25-25mbar
Gas group and gas connection pressure
as set at the factory (EN437)
B23, …., C93(x) Approved flue gas category (EN15502)
Tmax Maximum flow temperature in °C
IPX4D Electrical protection class
5.3 Combining units and options
INFORMATION
Certain options might not be available in your country.
5.3.1 Possible options for the outdoor unit
Drain pan (EKDP008CA)
The drain pan is required to gather the drain from the outdoor unit. The drain pan
kit consists of:
▪ Drain pan
▪ Installation brackets
For installation instructions, see the installation manual of the drain pan.
Drain pan heater (EKDPH008CA)
The drain pan heater is required to avoid freezing-up of the drain pan.
It is recommended to install this option in colder regions with possible low ambient
temperatures or heavy snowfall.
For installation instructions, see the installation manual of the drain pan heater.
