Bomann DR 921 CB [32/54] Cleaning and maintenance

Filling up the Water Boiler when using the Device

If there is no more water in the vessel no steam is emitted when

the steam switch (21) is pressed. The water has to be lled up

as follows:

1. Press the on/off switch (4). The red control lamp goes off.

2. Remove the mains plug from the socket!

3. Release the residual pressure with the steam switch (21)

(see “Initial Operation”, points 2 and 3).

WARNING: Danger of Injury!

Please open the safety lock (6) only when no more steam

comes out of the nozzle.

4. Slowly open the safety lock (6) and wait a few seconds

before opening it completely until the overpressure has

been released.

NOTE:

For your protection the safety lock has a release device. If

the pressure in the kettle is still too high, this release device

prevents it from being opened.

5. Fill freshwater from the measuring beaker (15) into the

kettle. Take care of water splashes that might come out

of the boiler. In order to avoid water spray, please use the

funnel supplied (Fig. E). Fill the water in slowly. Do not

overll! Max. water capacity: 1.5 litres.

6. Fasten the safety lock again.

7. Reinsert the plug into the socket and switch on the device

using the on/off switch.

When you have nished using the device

1. Press the on/off switch (4). The red control lamp goes off.

2. Remove the mains plug from the socket!

3. Release the residual pressure with the steam switch (21)

(see “Initial Operation”, points 2 and 3).

4. Allow the device to cool down for approx. 1 hour before you

put it away.

Cleaning and Maintenance

WARNING:

• Always remove the mains plug before cleaning the

device.

• Under no circumstances should you immerse the device

in water for cleaning purposes. Otherwise this might

result in an electric shock or re.

CAUTION:

• Do not use a wire brush or any abrasive items.

• Do not use any acidic or abrasive detergents.

Connected Wattage

The station has a total maximum wattage of 1500 W.

CAUTION: overload!

• If you use extension leads, these should have a cable

cross-section of at least. 1.5 mm².

• Do not use any multiple sockets, as this device is too

powerful.

Using the Device

CAUTION:

Before you begin cleaning you should test the materials to

be cleaned as to their suitability for cleaning with steam. Do

not hold the steam nozzle for too long and too close in one

position.

After you have lled the kettle with water and selected a clean-

ing attachment, please proceed as follows:

1. Turn the lock (22) on the steam pistol (20) to OFF/LOCK

without the steam switch (21) pressed in (Fig. A).

2. Connect the device to a duly installed 230 V/50 Hz protec-

tive contact socket.

3. Press the on/off switch (4) (Fig. F). The red control lamp (3)

lights up. The temperature control lamp (2) shows that the

device is heating up.

4. After approx. 12 min the steam temperature has been

reached and the temperature control lamp (2) goes off. The

device is ready for operation. During use this control lamp

shows that the water is being heated up again.

WARNING:

If the steam switch is pressed while the orange lamp is on, it

is possible for hot water to be ejected from the nozzle.

5. For the purposes of cleaning turn the lock (22) on the

steam pistol (20) to ON (Fig. B1).

6. Point the steam nozzle at the surface to be cleaned and

press the steam switch (21) (Fig. B2).

7. Use the lock (22) to turn the steam pistol to permanent

steam. Keep the steam switch pressed down and turn the

lock to OFF/LOCK at the same time (Fig. C3).

8. In order to release the lock again, please proceed as fol-

lows: hold down the steam switch and turn the lock to ON

at the same time (Fig. D4).

NOTE:

During operation please ensure that the hose does not

become twisted or squashed.
