3.5. CS-F34DTE5 CU-B34DBE8
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F34DTE5 CU-B34DBE8
Remote
Control
CZ-RD513C (Wired)
CZ-RL013T (Wireless)
Cooling Capacity kW 10
BTU/h 34,100
Heating Capacity kW 11.20
BTU/h 38,200
Refrigerant Charge-less m 30
Standard Air Volume for High Speed m
3
/min 29 94
cfm 1024 3316
Outside Dimension (H x W x D) mm 250 x 1600 x 700 1170 x 900 x 320
inch 9-27/32 x 62-31/32 x 27-9/16 46-1/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 43 (95) 100 (221)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.52 (3/8) Flared Type
Drain O.D Ø 20 I.D Ø 20
Compressor Type, Number of Set - Hermatic, 1
Starting Method - Permanent Split Capacitor
Motor Type - 2-pole 1 phase brushless motor
Rated Output kW - 3.00
Fan Type, Number of Set Sirocco fan-4 Mix flow fan-2
Motor Type 4-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.08 0.07 x 2
Air-heat Exchanger (Row x Stage x FPI) Slit-fin type (2 x 14 x 18) Corrugate-fin type (2 x 44 x 20)
Refrigerant Control - Expansion Valve
Refrigerant Oil (Charged) cm
3
- DAPHNE FVC68D (1500)
Refrigerant (Charged) R410a kg (oz) - 2.70 (95)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Noise Level dB (A) Cooling: 47/43 55/-
Heating: 47/43 56/-
Power Level
dB
Cooling: 64/60 69/-
Heating: 64/60 70/-
Moisture Removal L/h (Pt/h) 6.0 (12.6)
EER W/W 2.69/2.65/2.62
COP W/W 2.9/2.86/2.83
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature of 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Condition by ISO5151
Volts V 380 400 415
Phase Three Three Three
Power Consumption kW Cooling 3.72 3.77 3.82
Heating 3.86 3.91 3.96
Running Current A Cooling 6 6.1 6.2
Heating 6.3 6.4 6.5
Starting Current A 41 44 47
Power Factor % Cooling 94 89 86
Heating 93 88 85
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 3~380V, 400V, 415V 50Hz
13
