1.4. Operation range

1.4.1. Power Supply

The applicable voltage range for each unit is given in the following table. The working voltage among the three phases must be

balanced within a 3% deviation from each voltage at the compressor terminals. The starting voltage must be higher than 85% of

the rated voltage.

MODEL Unit Main Power Applicable Voltage

CU- Phase, Volts Hz Max Min

B24DBE5 1~220 50 242 198

B28DBE5 1~230 50 253 207

• Model 50Hz CU-B24DBE5 CU-B28DBE5 CU-B34DBE5 CU-B28DBE8 CU-B34DBE8 CU-B43DBE8 CU-B50DBE8

Operating Hz Indoor Temp. (D.B./W.B.) (°C) Outdoor Temp. (D.B./W.B.) (°C)

Max Min Max Min

Heating 50 27/- 16/- 24/18 -10/-
