9.7. Operation Control

9.7.1. Odour Cut Control

• Odour cut operation removes the odour generated at indoor heat exchanger by using drain water come out from indoor heat

exchanger.

• Press “Odour” button at remote control to enable odour cut operation.

• Odour cut operation starts when compressor or thermostat is on.

Thermostat &

Compressor ON/OFF

Thermostat & Compressor ON Thermostat & Compressor OFF Thermostat & Compressor ON

Time 40 sec. 50 sec. - 20 sec. 120 sec. 20 sec. 40 sec. 50 sec. -

Cooling Off Lo Normal

Operation

Lo Off Lo Off Lo Normal

Operation

Soft Dry Off Lo Lo Lo Off Lo Off Lo Lo

9.7.2. Drain pump Control

• During Cooling, Soft Dry or Deice operation, drain pump operates by following the table below.

• When compressor start, drain pump operating starts after 10 seconds of indoor fan starts.

• When operation stop or thermostat is off, drain pump continue operates for 6 minutes to prevent the drain water from coming

back.

9.7.3. Powerful Control

• To achieve setting temperature quickly.

• Cooling powerful operation:

• Setting temperature and thermostat shifting temperature are decrease by 2°C (lower limit 16°C).

− Airflow direction is optimized regardless the air flow setting at remote control.

− Fan speed is optimized at Hi regardless the fan speed setting at remote control.

• Soft Dry powerful operation:

− Setting temperature and thermostat shifting temperature are decrease by 2°C (lower limit 16°C).

− Airflow direction follows remote control setting.

• Heating powerful operation:

− Setting temperature and thermostat shifting temperature are increase by 2°C (upper limit 31°C).

− Airflow direction is optimized regardless the air flow setting at remote control.

− Fan speed is optimized at Hi regardless the fan speed setting at remote control.

• During powerful operation, the powerful indicator lights on.

• Powerful operation cancel when:

− Powerful operates for more than 15 minutes.
