3.8. Safety Devices
INDOOR UNIT
Indoor Unit Heati Pump Model CS-F24DTE5 CS-F28DTE5 CS-F34DTE5 CS-F43DTE5 CS-F50DTE5
Cooling only Model
For fan motor protection
Internal OFF °C 135 135 135 135 135
protector (49F) ON °C 87 87 85 85 85
For control protection
Fuse CUT A 3.15 3.15 3.15 3.15 3.15
OUTDOOR UNIT
Heat
Outdoor Unit Pump 50Hz CU-B24DBE5 CU-B28DBE5 CU-B28DBE8 CU-B34DBE8 CU-B34DBE8 CU-B43DBE8 CU-B50DBE8
Model
For refrigerant cycle
High pressure OFF Mpa 4.15 4.15 4.15 4.15 4.15 4.15 4.15
switch (63H1) ON Mpa 3.05 3.05 3.05 3.05 3.05 3.05 3.05
For compressor
Over current protection
Heat Pump Model OFF A 19 20 7.5 29 11 14 15
Cooling only Model OFF A — — —
RESET — Automatic Automatic Automatic Automatic Automatic Automatic Automatic
Discharge temperature
protection
Discharge
temperature
Com-
thermistor (Th1) pressor °C 115 115 115 120 120 120 120
OFF
Liquid compress
protection
Crankcase heater
Input
Power
W 37 37 37 37 37 37 37
Compressor
protection
Internal protector OFF °C 160 165 165 160 160 160 160
50Hz
ON °C 90 90 80 90 90 90 90
50Hz
trip
time 50Hz 3-10sec/65A 3-10sec/78A 3-10sec/26A — — — —
For fan motor
protection
Internal OFF °C 135 135 135 135 135 135 135
protector (49F) ON °C 85 85 85 86 86 86 86
Heating control
(Heat Pump only)
Pressure switch OFF Mpa _ _ _ _ _ _ _
(Fan speed) (63H2) ON Mpa _ _ _ _ _ _ _
Cooling control
Heat exchanger Th 40°C ——— High speed
outlet temperature Control method Th 40°C ——— 5 speed step control
thermistor (Th2)
For control
protection
Fuse CUT A 6.3 6.3 6.3 6.3 6.3 6.3 6.3
1Mpa=10.2kgf/cm
2
16
