Citizen CL-S321 [11/40] Printer setup
![Citizen CL-S321 [11/40] Printer setup](/views2/1843497/page11/bgb.png)
7
2 Printer Setup
3. Close the printing mechanism to complete the ribbon supply module loading.
Close the printing mechanism
Load The Ribbon On The Printer
For Ribbon Rewind Module
RIBBON REWIND MODULE
1. Place the right-hand side of empty ribbon core first.
Align the empty ribbon core
to the holder
Push the empty ribbon core
to tighten the spring of the holder
Right side
HOLDER
SPRING OF HOLDER
