Appendix
CL-S321/CL-S331 USER’S MANUAL
APPENDIX
PRODUCT SPECIFICATIONS
Model CL-S321 CL-S331
Print Method Thermal Transfer/Direct Thermal
Resolution 203dpi(8dots/mm) 300dpi(12dots/mm)
Print Speed 4IPS(102mm/s) 3IPS(76.2mm/s)
Print Width 4.25”(108mm) 4.16”(105.7mm)
Print Length Min. 0.16”(4mm)**; Max. 68”(1727mm) Min. 0.16”(4mm)**; Max. 30”(762mm)
Processor 32 Bit RISC CPU
Memory
Flash 8MB Flash(4MB for user storage)
SDRAM 16MB SDRAM
Sensor Type
Fixed transmissive sensor
Reflective sensor, central aligned
Media
Types
Continuous form, gap labels, black mark sensing, and punched hole; label length set by
auto sensing or programming
Width 1”(25.4mm)Min. -4.64”(118mm)Max.
Thickness 0.003”(0.06mm)Min.-0.008”(0.20mm)Max.
Label Roll
Diameter
Max. 5”(127mm)
Core Diameter 1”, 1.5”(25.4mm, 38.1mm)
Ribbon
Types Wax, wax/resin, resin
Length 360”(110m)
Width 1.18”Min.-4.33”(30mm-110mm)Max
Ribbon Roll
Diameter
1.57”(40mm)
Core Diameter 0.5”(12.7mm)
Printer Language EPL, ZPL auto switch
Software
Label Design
Software
BarTender Ultralite
Driver Windows 2000, XP, Vista, 7, Windows Server 2003&2008
Resident Fonts
Bitmap Fonts
6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A&B
Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Bitmap fonts 8 times expandable in horizontal and vertical directions
Scalable Fonts 90°, 180°, 270° rotatable
Download Fonts
Bitmap Fonts Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°, 180°, 270° rotatable
Asian Fonts
Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in horizontal and vertical
directions
Scalable Fonts Scalable fonts 90°, 180°, 270° rotatable
Barcodes
1-D Bar codes
Code 39, Code 93, EAN 8/13(add on 2 &5), UPC A/E(add on 2&5), I 2 of 5&I 2 of 5 with
Shipping Bearer Bars, Codabar, Code 128(subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/
EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey,
Telepen, FIM and GS1 DataBar
2-D Bar codes
PDF417, Datamatrix code, MaxiCode, QR code, Micro PDF417, Micro QR code and Aztec
code
Code Pages
CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863, 865, 866, 869, 737
WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257
Unicode UTF8, UTF16
Graphics
Resident graphic file types are BMP and PCX, other graphic formats are downloadable from
the software
Interfaces
USB Device (B-Type)
RS-232 (DB-9)
IEEE 802.3 10
100Base-Tx
Ethernet port (RJ-45)
USB Device (B-Type)
Parallel port
USB Device (B-Type)
RS-232 (DB-9)
IEEE 802.3 10
100Base-Tx
Ethernet port (RJ-45)
USB Device (B-Type)
Parallel port
Control Panel
One Tri-color LED: Power(Green, Orange and Red)
Function Key: FEED
Power Auto Switching 100-240VAC, 50-60Hz
