Citizen CL-S321 [14/40] Printer setup
![Citizen CL-S321 [14/40] Printer setup](/views2/1843497/page14/bge.png)
10
2 Printer Setup
Load The Label Roll Module On The Printer
1. Release the printing mechanism and lift it.
Open the printing mechanism
2. Place the label roll module on the printer.
Place on the printer
3. Pass the label through the printing mechanism.
Through the printing mechanism
