Citizen CL-S321 [17/40] Connecting the printer to the host computer
![Citizen CL-S321 [17/40] Connecting the printer to the host computer](/views2/1843497/page17/bg11.png)
13
2 Printer Setup
2.6 Connecting The Printer To The Host Computer
1. Please make sure that the printer is switched off.
2. Connect the power cord to the AC adapter.
POWER CORD
AC ADAPTER
Connect the jack of the power adapter to the printer and connect the plug of the power adapter to the
socket of the wall.
CL-S321 BARCODE PRINTER
POWER ADAPTER
JACK
PLUG
SLOT
SOCKET
THE WALL
