Citizen CL-S321 [6/40] Getting to know your printer
![Citizen CL-S321 [6/40] Getting to know your printer](/views2/1843497/page6/bg6.png)
2
1 Barcode Printer
1.2 Getting To Know Your Printer
Device Overview
• Front View
TOP COVER
COVER OPEN BUTTONS
Release buttons for opening the printer cover
LED OPERATION PANEL
FEED BUTTON
LED INDICATOR
• Rear View
FAN-FOLD LABEL INSERT
Feed slot for continuous labels
SERIAL PORT
ETHERNET PORT
USB PORT
POWER SLOT
POWER SWITCH
- ON
- OFF
