1 Barcode Printer
1.1 Box Content
Please check that all of the following items are included with your printer.
• CL-S321 Barcode Printer
• Label Supply Module
Label Supply Hub
• Ribbon Module
Empty Ribbon Core
• Power Adapter
Power Cord
Label Guide Plates(Set of 2) Ribbon AC Adapter
Label Stock
• CD
Including QLabel software and CL-S321/
CL-S331 user manual.
• CL-S321/CL-S331 Quick-Start
Guide
• USB Cable
CL-S321/CL-S331
Q
UICK-
S
TART
G
UIDE
Thermal Transfer Bar code
& Label Pr
inter
