! The appliance must be installed by a qualified person in
compliance with the instructions provided.
!
Wear gloves when carrying out installation and maintenance
operations.
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
Warning: Failure to install the screws or fixing device in accordance with
these instructions may result in electrical hazards.
The hood can look different to that illustrated in the drawings in this booklet.
The instructions for use, maintenance and installation, however, remain the
same.
AIR VENT
(for ducting versions)
! Prepare the hole and the air vent duct (150 mm diameter).
! Use a duct of the minimum indispensible length.
! Use a duct with as few elbows as possible (maximum elbow angle: 90°).
! Avoid drastic changes in the duct cross-section.
! Use a duct with an as smooth as possible inside.
! The duct must be made of certified material.
! Do not connect the hood to smoke exhaust ducts for the products of
combustion (boilers, fireplaces, stoves, etc).
! For the air vents comply with the provisions laid down by the competent
authorities.
In addition, the air must not be evacuated through a hole in the wall
unless specifically intended for this purpose.
! Fit air intakes in the room to prevent the hood from creating a negative
pressure in the room (which must not exceed 0.04 mbar); if the hood is
used at the same time as non-electrical equipment (gas-, oil- and
charcoal-fired stoves, etc.) the exhaust gas may be sucked in by the
heat source.
FILTERING OR DUCTING VERSION ?
The hood may be in filtering or in ducting version. Decide from the outset
which type is to be installed.
For better efficiency, we recommend installing the hood in the ducting
version (if possible).
Ducting version
The hood purifies the air and evacuates it to the outside through an
exhaust duct (diameter 150 mm).
Filtering version
The hood purifies the air and recycles the clean air back into the room. For
this version, the following are required: 1 air baffle, 1 reducer, 1 charcoal
filter. The upper flue air evacuation slots must be positioned at the top.
Only for hoods equipped with electronic control:
The 4th speed (intensive) is automatically lowered to 3rd speed after 5
minutes of operation to optimise energy consumption; in hoods with
voltage 120V/60Hz this function is not active and the 4th speed is
indicated by the letter b (Booster).
- If the hood is left on (lights and/or motor), after 10 hours in the absence
of commands from the user, it will automatically switch to OFF condition
with all services switched off. In hoods with voltage 120V/60Hz this
function is not active.
- The Buzzer emits a “beep” each time that a command is set from the
keyboard or remote control (optional).
- In the event of interruption of power during the hood, if you restore
the hood in the OFF state, then the engine must be reactivate manually.
Only for hoods equipped with infrared sensor controls: The unit is
equipped with infrared sensor controls that, if exposed to direct sunlight
may not work properly; use curtains or other devices to shield the sunlight.
CONTROLS
Controls of Fig. 33
A) Turns the LIGHTS off.
B) Turns the LIGHTS on.
C) Decreases speed down to minimum speed. If pressed for 2” the motor is
turned off.
D) Activates the motor (calling the last speed used) and increases the
speed until reaching maximum.
E) FILTER ALARM/TIMER RESET: when pressing the key during display of
the filter alarm (motor off) its reset the hour counter. When pressing the
key when the motor is running, the TIMER is activated and the hood will
automatically be switched off after 5 minutes.
L1) The 4 green LEDs indicate the running speed.
L2) When the LED is red (motor off) it indicates the FILTER ALARM. When
the LED is green (flashing) it indicates that the TIMER has been activated
with the key E.
FILTER ALARM:
After 30h of operation, the LED L2 turns RED. It indicates that the grease
filters need to be cleaned.
After 120h of operation, the LED L2 turns RED and flashes; It indicates
that the grease filters need to be cleaned and the charcoal filters replaced.
After cleaning the grease filters (and/or replacing the charcoal filters),
restart the hour counter (RESET) by pressing the key E during display of
the filter alarm.
Controls of Fig. 34
A) Lights OFF: If pressed, lights go off.
B) Lights ON: If pressed, lights go on.
C) OFF/- Motor: Speed drop until minimum speed is reached. If pressed for
2”, motor switches off. If pressed for 2” with FILTER RESET on HOUR
count reset.
D) ON/+ Motor: Starts motor and increases motor speed until top speed is
reached
E) ON/OFF: Switches Sensor off and on( AUTOMATIC or MANUAL
mode).In Automatic mode, LED L2 is on and L1 shows operating speed In
Manual mode, LED L2 is off.
L1) 4 LEDs 4 GREEN LEDs. Indicate set speed
L2) 4 LEDs GREEN indicates AUTOMATIC mode OFF indicates MANUAL
mode RED indicates Filter Reset.
FILTER RESET: shown with Motor Off for 30”: After 30h the LED L2
becomes steady RED. After 120h LED L2 becomes flashing RED Reset
by means of C.
SENSITIVITY: In manual mode, by pressing E and D together, sensitivity
mode is entered. The set sensitivity is indicated by the 4 green LEDs. By
means of buttons C(-) and D(+) the desired sensitivity is set.By pressing
P5 the sensitivity can be stored, with return to manual mode.
Attention: To prevent damaging the sensor, do not use silicone products
near the hood!
Controls of Fig. 35
Key A: light switch.
Key B: first speed motor ON/OFF switch.
Key C: second speed switch.
Key D: third speed switch.
Controls of Fig. 36
Key A: light switch.
Key B: first speed motor ON/OFF switch.
Key C: second speed motor ON/OFF button.
Key D: third speed motor ON/OFF button.
E: motor on light.
Controls of Fig. 37-38-39
Button A = turns the lights on/off.
Button B = turns the TIMER on/off: press once to turn the timer on,
therefore, after 5 minutes, the motor cuts out (at the same time the
selected speed blinks on the display); the timer remains on if the motor
speed is changed.
Display C = - indicates the selected motor speed (from 1 to 4); - indicates
Timer On when the number blinks; - indicates Filter Alarm when the central
segments is on or blinking.
Button D = makes the motor work; pushing the button again, the speeds of
the motor are sequentially selected from 1 to 4; keeping this button pressed
for about 2 seconds shuts down the motor.
Button R = resets the grease filters or charcoal filters; when the filter alarm
appears (i.e. when the central segment on the display goes on), the grease
filters must be cleaned (30 hours of operation); when the central segment
starts blinking, the grease filters must be cleaned and the charcoal filters
replaced (120 hours of operation). Obviously, if the hood is not a filtering
model and does not have a charcoal filter, clean the grease filters both
when the central segment goes on and when it starts blinking. The filter
alarm can be seen when the motor is off and for about 30 seconds. To
reset the hour counter, keep the button pressed for 2 seconds while the
