2. Examples of Using ESC/P Brother Commands

This is the document that will be made.

1 inch

Step 1:

Landscape

Paper size

Step 2:

Horizontal position

Step 3:

Vertical position

Step 4

Font type: Helsinki

(proportional pitch)

Step 5:

Character size

: 100 dots

In order to make this document, the following six steps are required.

Step 1: Select the landscape orientation.

Entered command

ESC i L

01h
