ESC/P Brother Command Reference

- 9 -

2. Examples of Using ESC/P Brother Commands

Step 5: Specify the character size.

Character size=n1+n2*256=100 dots

ESC X 00h 64h

00h

Entered

command

= =

100

64h

00h

Character size: 100 dots

Example: A case

203dpi

printer is used
