Chapter 2: Basic Installation

Chapter 2

• We recommend using a

LGA1700 compatible cooling

system on an Intel

600 & 700

series motherboard.

• Additional holes for LGA1200

compatible cooling systems are

also available on ASUS’ Intel

600 & 700 series motherboards,

however, we still strongly advise

consulting with your cooling

system vendor or manufacturer

on the compatibility and

functionality of the cooling

system.

• Push-pin type LGA1200

compatible cooling systems

cannot be installed to this

motherboard.

LGA1200

LGA1700
