PRIME Z790-P WIFI D4
2-17
Chapter 2
* and ** : Refer to the tables on the next page for LAN port LEDs, and audio port definitions.
Rear panel connectors
1. DisplayPort
2. PS/2 Keyboard/Mouse combo port
3. Realtek 2.5Gb Ethernet port*
4. USB 3.2 Gen 2 Type-A port 3
5. HDMI
®
port
6. USB 2.0 ports E5, E6, E7 and E8
7. USB 3.2 Gen 1 Type-A ports 9 and 10
8. USB 3.2 Gen 2x2 Type-C
®
port 1
9. Audio Jacks**
10. Wi-Fi 6 ports
We strongly recommend that you connect your devices to ports with matching data
transfer rate. Please connect your USB 3.2 Gen 1 devices to USB 3.2 Gen 1 ports and
your USB 3.2 Gen 2 devices to USB 3.2 Gen 2 ports for faster and better performance for
your devices.
ACT/LINK
LED
SPEED
LED
Ethernet port
* Realtek 2.5G Ethernet port LED indications
Speed LED
Status Description
OFF No link
GREEN 2.5 Gbps connection
ORANGE 1 Gbps / 100 Mbps /
10 Mbps connection
Activity Link LED
Status Description
OFF
No link
GREEN
Linked
BLINKING
Data activity
USB_E5 port, USB_E6 port, USB_E7 port and USB_E8 port share the bandwidth.
** Audio 2, 4, 5.1 or 7.1-channel configuration
Port 2-channel 4-channel 5.1-channel 7.1-channel
Light Blue
(Rear panel)
- -
Rear Speaker
Out
Rear Speaker
Out
Lime
(Rear panel)
Front Speaker
Out
Front Speaker
Out
Front Speaker
Out
Front Speaker
Out
Pink
(Rear panel)
-
Center/
Subwoofer
Center/
Subwoofer
Center/
Subwoofer
Lime
(Front panel)
- - -
Side Speaker
Out
Pink
(Front panel)
- - - -
To configure a 7.1-channel audio output:
Use a chassis with HD audio module in the front panel to support a 7.1-channel audio
output.
