Asus PRIME Z790-P WIFI D4 [43/66] Front i o connector

PRIME Z790-P WIFI D4

2-13

Chapter 2

2.1.8 Front I/O connector

To install front panel connector

USB 2.0

AAFP

To install USB 2.0 connector

To install front panel audio connector

USB 3.2 Gen 1

To install USB 3.2 Gen 1 connector

This connector will only fit in one

orientation. Push the connector until it

clicks into place.

USB 3.2 Gen 2 Type-C

To install USB 3.2 Gen 2 Type-C

connector
