Asus PRIME Z790-P WIFI D4 [39/66] Motherboard installation

PRIME Z790-P WIFI D4

2-9

Chapter 2

2.1.5 Motherboard installation

1. Install the ASUS I/O Shield to the chassis rear I/O panel.

Some sharp edges and points might cause physical injury. We recommend you put on cut

or puncture resistant gloves before motherboard and I/O shield installation.

2. Place the motherboard into the chassis, ensuring that its rear I/O ports are aligned to

the chassis’ rear I/O panel.
