Asus PRIME Z790-P WIFI D4 [37/66] M installation

PRIME Z790-P WIFI D4

2-7

Chapter 2

2.1.4 M.2 installation

OPTIONAL

• Ensure to install the bundled M.2 rubber pad before installing your single sided M.2

storage device.

• DO NOT install the bundled M.2 rubber pads when installing a double-sided M.2

storage device. The rubber pad installed by default is compatible with double sided

M.2 storage devices.

To install an M.2 SSD card
