Asus PRIME Z790-P WIFI D4 [35/66] Chapter 2

PRIME Z790-P WIFI D4

2-5

Chapter 2

To install an AIO cooler

• We recommend using a LGA1700 compatible cooling system on an Intel

600 & 700

series motherboard.

• Additional holes for LGA1200 compatible cooling systems are also available on

ASUS’ Intel

600 & 700 series motherboards, however, we still strongly advise

consulting with your cooling system vendor or manufacturer on the compatibility and

functionality of the cooling system.

• If you wish to install an AIO cooler, we recommend installing the AIO cooler after

installing the motherboard into the chassis.

AIO_PUMP

CPU_OPT

CPU_FAN
