2.3 Installing Memory Modules (DIMM)

is motherboard provides four 288-pin DDR4 (Double Data Rate 4) DIMM slots,

and supports Dual Channel Memory Technology.

Recommended Memory Conguration

1 DIMM

2 DIMMs

4 DIMMs

A1 A2 B1 B2

V V

A1 A2 B1 B2

V V V V

1. For dual channel conguration, you always need to install identical (the same

brand, speed, size and chip-type) DDR4 DIMM pairs.

2. It is unable to activate Dual Channel Memory Technology with only one or three

memory module installed.

3. It is not allowed to install a DDR, DDR2 or DDR3 memory module into a DDR4

slot; otherwise, this motherboard and DIMM may be damaged.

4. e DIMM only ts in one correct orientation. It will cause permanent damage to

the motherboard and the DIMM if you force the DIMM into the slot at incorrect

orientation.
