ASRock B760 Pro RS/D4 [47/59] Post status checker
![ASRock B760 Pro RS/D4 [47/59] Post status checker](/views2/1921000/page47/bg2f.png)
43
B760 Pro RS/D4
2.13 Post Status Checker
Post Status Checker (PSC) diagnoses the computer when users power on the
machine. It emits a red light to indicate whether the CPU, memory, VGA or
storage is dysfunctional. e lights go o if the four mentioned above are function-
ing normally.
BOOT
DRAM
VGA
CPU
