39
B760 Pro RS/D4
underbolt AIC Connector
(5-pin TB1) (see p.6, No. 29)
Please connect a underbolt™ add-in card (AIC) to the underbolt AIC connector via
the GPIO cable.
*Please install the underbolt™ AIC card to PCIE3 (default slot).
1
TB1
