ASRock B760 Pro RS/D4 [7/59] Rear panel i o
![ASRock B760 Pro RS/D4 [7/59] Rear panel i o](/views2/1921000/page7/bg7.png)
3
B760 Pro RS/D4
Graphics
•
Intel® UHD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
•
Intel® X
e
Graphics Architecture (Gen 12)
•
1 x HDMI 2.1 TMDS Compatible, supports HDCP 2.3 and
max. resolution up to 4K 60Hz
•
1 x DisplayPort 1.4 with DSC (compressed), supports HDCP
2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
Audio
•
7.1 CH HD Audio (Realtek ALC897 Audio Codec)
•
Nahimic Audio
LAN
•
2.5 Gigabit LAN 10/100/1000/2500 Mb/s
•
Dragon RTL8125BG
•
Supports Dragon 2.5G LAN Soware
- Smart Auto Adjust Bandwidth Control
- Visual User Friendly UI
- Visual Network Usage Statistics
- Optimized Default Setting for Game, Browser, and
Streaming Modes
- User Customized Priority Control
USB
•
1 x USB 3.2 Gen2 Type-C (Front)
•
1 x USB 3.2 Gen1 Type-C (Rear)
•
7 x USB 3.2 Gen1 Type-A (5 Rear, 2 Front)
•
4 x USB 2.0 (2 Rear, 2 Front)
* All USB ports support ESD Protection
Rear Panel
I/O
•
2 x Antenna Mounting Points
•
1 x HDMI Port
•
1 x DisplayPort 1.4
•
1 x USB 3.2 Gen1 Type-C Port
•
5 x USB 3.2 Gen1 Type-A Ports
